The basic knowledge of sheet aluminium:
1, dimensional tolerance deviation: high precision and ordinary grade.
The dimensional deviation of the sheet aluminum shall comply with the provisions of GB/T3880.3. If a size deviation is required to use high precision, it should be marked in the contract and supplied at the ordinary level without marking.
2, tensile strength: the maximum tensile force that the sample area can bear. Pull / area Pa= ox / mm2 Pa=Pa*106
3,Hardness: sample can withstand maximum pressure on unit area.Pressure/surface area (the pressure on the surface of the round), general cloth di hardness (HB)
4,Elongation: the maximum elongation length measured after the unit is broken.
The characteristic of aluminium sheet metal:
1.Dark green surface, color changed into light green after exposure.Image checked easily.
2.Surface Quality :be free from Oil Stain, Dent, Inclusion, Scratches,Stain, Oxide Dicoloration, Breaks, Corrosion, Roll Marks, Dirt Streaks and other defect which will interferewi
3.Faithful reproduction capacity, result at clear images.
4.Highly durable, long impression available.
5.Excellent sensitive character.
6.Resolution : 2%-98%
7.Material:1050/1060/1070/1100/2A16/2A06/2A12/3003/3004/3A21/4A01/5052/5005/5083/5A05/6061-T6/ 6063-T5/7075-T6/8011
Material |
1000 series: 1050. 1070. 1100 |
2000 series: 2011. 2014. 2017. 2018. 2024. 2025. 2117. 2218. 2618. |
|
3000 series: 3003. 3004. |
|
4000 series: 4032. 4043. 4543. |
|
5000 series: 5005. 5050. 5052. 5056. 5083.5086. 5154. 5205. 5252. 5254. 5356. 5357. 5454. 5456. 5457. 5652. 5657. |
|
6000 series: 6005. 6011. 6053. 6351. 6061. 6101. 6151. 6201. 6261.6262.6063.6463.6066.6070 |
|
7000series: 7001. 7005. 7072. 7075. 7076. 7175. 7178. 7079.7075 |
|
8000 series:8011,8021,8079 etc |
|
Temper |
T4,T5,T6,H111,H112 |
Mechanical property of alloy aluminum sheet :
Aluminum sheet |
||||
AlloyNo. |
Thickness(mm) |
Width(mm) |
Length(mm) |
Temper |
A1050,A1060,A1070,A1100 |
0.2-100 |
20-2200 |
20-8000 |
O,H12,H22,H14,H16,H18,H24,H26,etc |
3A21,A3003,A3105,A3004 |
0.2-100 |
20-2200 |
20-8000 |
O,H14,H18,H24,etc |
A5052,A5005,A5083,A5754 |
0.2-100 |
20-2200 |
20-8000 |
O,H18,H24,H32,H34,H111,H112,etc |
A6061,A6082,A6063 |
0.2-200 |
20-2200 |
20-8000 |
T4,T6,T651,etc |
A8011 |
0.2-100 |
20-2200 |
20-8000 |
O,H12,H22,H14,H16,H18,H24,H26 |
